Dried natural quartz silica sands

Silica or also called quartz sand is sorted by wet and dry screening processes. Our Quartz Q silica sands are fire dried in our industrial processes. Quartz Q posseses a hygiene certificate for building products and filtermedia. It is available in 20 standard primary fractions, other granulations on request.

It is mainly used for applications as:

Filter medium for water processing plants. As a filler in resin bonded flooring systems, based on epoxy-based resins, polyurethanes or methyl methacrylate. Also it finds application in so called cementbased dry-mix mortar systems as a dry filler. This to achieve excellent products as plasters, concrete, cementbased floorings, mortars or tile clay. Quartz Q can also be used for decorative or functional prefab building elements.

Dried sand is also used in concrete products, sport fields, wet-blasting, water filtration, as well as roofingsystems (protection and isolation), gardens ,terraces, children playgrounds, roads and aquariums.

Our sand has a high abrasion resistance and good natural strength parameters. Also it is precisely sorted in industrial processes.


    Technical specifications:
  • Quartz Hardness (Mohs): 7
  • Density: 2,65 g/cm³
  • Humidity: 0,1%
  • Weight compact: 1,55 t/m³

It is standard packed in 25 kg PE ventile bags / Big Bag of 1000 kg / 25 kg paper bags on request

Available standard granulations

  • QD 0,1-0,2 mm
  • QS 0,1-0,3 mm
  • QQ 0,1-0,4 mm
  • QQ 0,1-0,5 mm
  • QQ 0,2-0,6 mm
  • QQ 0,2-0,8 mm
  • QQ 0,4-0,9 mm (before 0,4-0,8)
  • QQ 0,5-1,0 mm
  • QS 0,8-1,0 mm
  • QS 0,7-1,2 mm
  • QS 0,8-1,2G mm
  • QS 1,0-1,6 mm
  • QQ 1,0-1,7 mm
  • QQ 1,0-2,0 mm
  • QQ 1,0-2,2 mm
  • QQ 1,6-2,2 mm
  • QQ 2,0-3,0 mm
  • QQ 2,0-4,0 mm
  • QS 3,0-5,0 mm
  • QS 4,0-6,0 mm
  • QS 5,0-8,0 mm

Technical datasheet Leaflet Blue Quartz Q
Technical datasheet BW Quartz Q
Sieve analysis all granulations
Hygienic radiation certificate This email address is being protected from spambots. You need JavaScript enabled to view it. This email address is being protected from spambots. You need JavaScript enabled to view it. This email address is being protected from spambots. You need JavaScript enabled to view it.
Hygienic certificate for building materials This email address is being protected from spambots. You need JavaScript enabled to view it. This email address is being protected from spambots. You need JavaScript enabled to view it. This email address is being protected from spambots. You need JavaScript enabled to view it.
Hygienic certificate for filtration media This email address is being protected from spambots. You need JavaScript enabled to view it. This email address is being protected from spambots. You need JavaScript enabled to view it. This email address is being protected from spambots. You need JavaScript enabled to view it.
